Juniper 허브의 유용한 명령어와 사용예시
모드 변경
cli : Unix -> operation mode
configure : operation mode -> configuration mode
run : configuration mode -> operation mode
configuration mode 설정
root 비밀번호 설정
set system root-authentication plain-text-password
허브 설정 초기화
load factory-default
set system root-authentication plain-text-password
commit and-quit (저장후 종료)
혹은 start shell (configuration 모드 아님)
cd /config
rm -r *
reboot
poe 활성화
set poe interface all
set poe interface ge-0/0/0
set poe interface range ~~
유용 명령어
show | compare : 뭐가 변경되었는지 보여줌 + - 이런식으로 git 와 같이
commit : 커밋임
commit check : 커밋했을때 제대로 됬는지 확인
set system host-name ~~~ : hostname 지정
set interfaces ge-0/0/0/ unit 0 family inet address 192.168.1.1/24 :
L3장치의 port를 192.168.1.1 주소 등록 (3계층으로 동작시킬려면 inet을 추가하고 ether-switching을 del 시켜줘야한다.)
set interfaces ge-0/0/0 disable : ge-0/0/0 인터페이스 끄기delete interfaces ge-0/0/0 disable : ge-0/0/0 인터페이스 켜기
run show interfaces terse ge-0/0/0 : ge-0/0/0 인터페이스 확인
show system alarms : 왜 스위치에 alarm에 불들어왔는지 확인
PASSWORD RECOVERY
FreeBSD/MIPS U-Boot bootstrap loader , Revision 0.1
(vishal@slt-pool1-0.3.juniper.net, Web Mar 18 11:41:32 PDT 2009)
Memory: 2048M
Loading /boot/defaults/loader.conf
/kernel data=0x90ca48+0xc6ac4 syms=[0x4+0x74470+0x4+0x4+0xa4910]
Hit [Enter] ro boot immediatrly, or space bar for command prompt. ---> 부팅시 좌측 메시지가 보이면 스페이스바 (엄청 빨리 넘어가니까 대기 잘타셔야됨..)
Booting [/kernel] in 1 second...
Type '?' for a list of commands, 'help' for more detailed help.
loader> boot -s 입력
kernel entry at 0x801000d8...
getbootinfo: magic 0x0 md 0x80bee000 memsize 0x0
WARNING: System coming up from legacy bootloader.
중간생략
System watchdog timer disabled
Enter full pathname of shell or 'recovery' for root password recovery or RETURN for /bin/sh: recovery 입력
performing system setup ...
** /dev/bo0os3e
중간생략
PASSWORD RECOVERY (CONT)
Starting CLI ...
root> configure
Entering configuration mode
[edit]
root# set system root-authentication plain-text-password
New password :
Retype new password :
[edit]
root# commit
root password 설정 후, commit 으로 저장 후 재부팅
VLAN 설정 하는법 예시 (https://kb.juniper.net/InfoCenter/index?page=content&id=KB16354)
Configure a VLAN:
user@juniper# set vlans vlan10 vlan-id 10
Configure the interface range "test" to be a part of a vlan (vlan10, in this case):
user@juniper# set interfaces interface-range test unit 0 family ethernet-switching vlan members vlan10
Add member interfaces (actual physical interface) to the interface range:
user@juniper# set interfaces interface-range test member-range ge-0/0/0 to ge-0/0/10
user@juniper# commit check
configuration check succeeds
user@juniper# commit
configuration check succeeds
commit complete
Verify that all physical interfaces in the interface range have become part of the member VLAN to which the "test" interface range was added:
user@juniper# run show vlans
Name Tag Interfaces
default
ge-0/0/11.0, ge-0/0/12.0, ge-0/0/13.0, ge-0/0/14.0,
ge-0/0/15.0, ge-0/0/16.0*, ge-0/0/17.0, ge-0/0/18.0,
ge-0/0/19.0, ge-0/0/20.0, ge-0/0/21.0, ge-0/0/22.0,
ge-0/0/23.0, ge-0/1/0.0
vlan10 10 <<<<<<< Interfaces ge-0/0/0 - ge-0/0/10 in vlan10
ge-0/0/0.0, ge-0/0/1.0, ge-0/0/2.0, ge-0/0/3.0,
ge-0/0/4.0, ge-0/0/5.0, ge-0/0/6.0, ge-0/0/7.0,
ge-0/0/8.0, ge-0/0/9.0, ge-0/0/10.0*
user@juniper# edit interfaces interface-range test
[edit interfaces interface-range test]
user@juniper# show
member-range ge-0/0/0 to ge-0/0/10;
unit 0 {
family ethernet-switching {
vlan {
members 10;
}
}
}
Firewall filter (Access-list)
1. Firewall filter 정의
set firewall family inet filter <acl name> term <term name> from < match>
set firewall family inet filter <acl name> term <term name> then < action>
<ACL NAME> : Interface 에 적용할 ACL NAME 정의
<Term name> : ACL Line에 대한 Description
<Match> : Mac, IP, Protocol, Layer4 Port의 ACL Matching을 위한 조건 정의
<Action> : Packet을 deny or permit 할 것인지 action 정의
* Action 종류
Discard : packet을 deny함.
accept : packet을 permit 함
2. Interface에 input/output 방향으로 적용
set interfaces vlan unit 10 family inet filter input <ACL NAME>
( 1.1.1.1/32 에서 1.1.1.2/32 으로 가는 packet만 discard 하고, 나머지 packet 은 forwarding)
-------------------- ---------------------------------------
1. firewall filter(acl) 만들기
juniper@EX2# set firewall family inet filter blockhost term 1 from source-address 1.1.1.1/32
juniper@EX2# set firewall family inet filter blockhost term 1 from destination-address 1.1.1.2/32
juniper@EX2# set firewall family inet filter blockhost term 1 then discard
juniper@EX2# set firewall family inet filter blockhost term 2 then accept
juniper@EX2# set firewall family inet filter blockhost term 2 then count blockcount (counter 옵션)
2. interface에 적용하기
juniper@EX2# set interfaces vlan unit 10 family inet filter input blockhost
juniper@EX2# set interfaces vlan unit 20 family inet filter input blockhost
3. counter 확인하기
juniper@EX2# run show firewall filter blockhost
Filter: blockhost
Counters:
Name Bytes Packets
blockcount 0 0
